◆Spring Self-Centering when within 25 degree of the Closed Position
◆Preset 90 degree pivot pin for normal door closing operation, available revsersible 5 degree pivot pin or custom pivot pin
◆50000 cycles open/close, 3 Year Warranty
◆Using two hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 90 lbs. (41 kg) with a maximum door width of 31 1/2" (800 mm).
◆Using three hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 130 lbs. (59 kg) with a maximum door width of 36" (914 mm).
◆Suitable Glass: 5/16" (8 mm) to 1/2" (12 mm) Tempered Safety Glass, It is RECOMMENDED that only Tempered Safety Glass is used with these hinges.
Brass Shower Room Wall-mounted 90 Degrees Glass Shower Door Hinge
Model:SH220-90S-WTG
European Style Solid Brass Glass Door Hinge Beveled Edge
Model:SH250-90T-WTG
Square Adjustable Shower Hinge 90 degree
Model:SH160-90L-WTG-AD
