◆Spring Self-Centering when within 15 degree of the Closed Position
◆Can be adjusted to any angle up to 90 DEG without taking the door down
◆50000 cycles open/close, 3 Year Warranty
◆Using two hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 80 lbs. (36 kg) with a maximum door width of 28" (711 mm).
◆Using three hinges with 5/16" to 1/2" glass (8 to 12 mm) the hinge will hold up to 120 lbs. (54 kg) with a maximum door width of 32" (813 mm).
◆Suitable Glass: 5/16" (8 mm) to 1/2" (12 mm) Tempered Safety Glass, It is RECOMMENDED that only Tempered Safety Glass is used with these
Micro Glass Hinge 90 Degree
Model:SH154-90T-WTG-SM
V shape Shower Glass Door Pivot Hinge
Model:SH150-90V-WTG
90 Degree Square Standard Shower Hinge
Model:SH150-90LL-WTG
